Mbr technology, or Multi-Stage Bypass Ring, embodies a genuine multi-stage bypass system where each zone is independently adjustable via a positive stop helix system. This design ensures ample flow, similar to 7-tube External bypasses on 16 inch stroke variations, and internal free bleed ports enable tuners to optimize the damping curve for specific vehicle needs.

A true top-out zone provides both mechanical and hydraulic damping, guarding against shock damage during full extension in harsh conditions, although the use of limit straps is recommended for racing and severe use. Additionally, the 4-way adjustable reservoir allows independent high and low-speed adjustments for compression and rebound events.

A dual hose system establishes a genuine recirculating fluid path to the reservoir, maximizing fluid cooling with internal diverters ensuring fluid flow across the entire shock body for enhanced cooling efficiency. Each unit undergoes vacuum bleeding and features full synthetic fluid to reduce fade and extend product life.

Features and Benefits:

• Hard-chrome plated steel shock shafts for superior corrosion resistance
• Shock eye mounts feature machined rod ends with high strength spherical bearings for increased performance
• Shaeffer's high grade temperature stable synthetic hydraulic fluid
• Fully rebuildable
• Made in America

Details:

• Collapsed Length: 26 Inch
• Stroke: 16 Inch
• Grade Type: Performance
• Mounting Hardware Included: No
• Finish: Ceramic Coated
• Active or Passive Suspension: Passive
• Adjustable Compression: Yes
• Adjustable Rebound: Yes
• Adjustable Reservoir: Yes
• Adjustable Ride Height: Yes
• Body Color: Black
• Diameter: 3 Inch
• Body Material: Steel
• Coil Spring Insulator(s) Included: No
• Damping Type: Oil
• Dust Bood Included: No
• Dust Shield Included: No
• Extended Length: 42 Inch
• Includes Bump Stop: No
• Internal Construction Type: Monotube
• Internal Rebound Bumper: No
• Internal Rebound Spring: No
• Travel Length: 16 Inch
• Lower Mount Type: Eye
• Upper Mount Type: Eye
• Remote Reservoir: No
• Self-Leveling: No
• Shaft Diameter: 0.875 Inch
• Shaft Material: Hard-chrome plated steel
• Spring Included: No
• Spring Rate: Pounds Per Inch
• Strut Mount Insulator(s) Included: No
• Valving Type: Progressive
• Mounting Width and Bolt Size: 1.5 inch x .500 inch
